GP-X Measurement Sensor
GP-X INDUCTIVE ANALOGUE SENSORS (CONTROLLER)
The inductive displacement transducers of the GP-X series use eddy current techniques and are particularly noted for their highly accurate measurement at a resolution of 0.02% F.S. with minimal linearity error, a high sampling frequency of 40kHz and low temperature dependence.
-
GT03-E
New Models Added to the GT Tough Series
GT03-E Compact Models Debut
[vc_btn title="Download PDF" color="warning" link="url:#||target:%20_blank|"]
-
GX Inductive Sensor
Cylindrical inductive sensors
The GX cylindrical inductive sensor series with a built-in amplifier comes in two versions - with and without a threaded section. Numerous special types allow you to select the optimum sensor for your application. GX sensors have a large sensing range and come with an indicator LED, which makes it easy for you to check the operation. GX series sensors have robust cases and reinforced cables whose lifetime is 10 times that of conventional connecting cables.
-
GX-F/H Inductive Sensor
Rectangular inductive proximity sensors
Industry's no. 1* in stable sensing. This sensor has the longest stable sensing range among comparable rectangular inductive proximity sensors in the industry.
The sensor is easy to install. Precise adjustment and control of sensing sensitivity greatly reduces individual sensor differences and variations.
-
GX-M Inductive Sensor
Cylindrical inductive sensors
The GX-M series cylindrical inductive sensors come in many variations.
In addition to various rated sensing distances, 2- and 3-wire types are available, as well as shielded and non-shielded models.
All models are equipped with an LED that lets you verify when the output is on at a glance.
-
GXL Inductive Sensor
Inductive sensors, cuboid design
These cuboid, inductive proximity sensors are extremely small. Each sensor is available in four different versions: front or side sensing with normally open or normally closed contacts and offering two detection frequencies to prevent mutual interference.
-
-
HG-C Measurement Sensor
HG-C series
As compact as a photoelectric sensor, the CMOS laser sensor allows to display actual measured distance as accurately as a displacement sensor.
- Accurate > Linearity: +/-0.1% F.S.
- Compact & light weight > W20mm x H44mm x D25mm
- Precise level detection > Repeatability: 10μm
-
HG-S Communication Unit
Direct transfer of high-precision measurement values: new communication unit for the HG-S series
The new RS485 communication unit for the HG-S sensor series is used to transfer high-precision measurement values directly, making data traceability easier than before.
-
HG-S Measurement Sensor
Slim unit body
- Slim & robust pencil-type sensor unit
- Bending-resistant cable even when used for moving parts
- Hot-swappable
- Plain bearings with 2-point support structure ensure excellent resistance to lateral loads
- Resistance to lateral load
- High accuracy: The high-precision sensor head has a resolution of 0.1µm and an indication accuracy of max. 1µm for the full range and max. 0.5µm for the narrow range. The high-resolution CMOS sensors measure the amount of movement by reading the glass scales that have different slit patterns at different read positions. This provides accurate measurements even in high-speed measuring operations. It also eliminates mechanical zero position runs when the system has been switched on.
- Resistance to upward thrust impact: Even when a sudden upward thrust impact occurs, the resulting load is applied only to the lower section of the sensor unit. The spindle stopper minimizes the impact on the glass scales.
- Tip deviation amount of max. 35µm
-
HL-C2 Measurement Sensor
HL-C2 sensor heads
By combining our accumulated know-how in measurement technology with the latest digital technology, we have created the versatile laser displacement sensor HL-C2, the best sensor in its class. Even for extremely difficult applications such as measuring variations in HDD surfaces or sensing very shiny objects, the HL-C2 sensor functions stably and consistently.
-
HL-D3 Measurement sensor
High-precision measurement sensor
- High-precision measurement sensor with a resolution of 1μm.
- The functionality of 500 displacement sensors in a device that is just 12.5mm wide!
- Height measurement range (i.e. sensing range on the Z axis): 50 ± 10mm
- Center point of the height measurement range: 50mm
- Width measurement range (i.e. sensing range on the X axis): 12.5mm
- Sampling rate: max. 80µs
- Resolution: 1µm
-
HL-G1 Measurement Sensor
HL-G1 Series
Panasonic has developed and produced laser distance sensors for more than 20 years. Using our well established triangulation method and state-of-the-art laser technology, our sensors are able to handle high resolution measurement regardless of background color and surface conditions.
